ASI - 10-1204-60 - Shower Curtain Rod w/ Flanges - 1 1/4" Diameter, 60" L

Straight stainless steel shower curtain rod, 1-1/4" (32 mm) diameter, installed between two wall-mounted end flanges.

• Length: 60" (1524 mm)
• Flanges: 20 gauge Type 304 stainless steel, satin finish, 3-3/16" (81 mm) diameter x 1/2" (13 mm) deep
• Mounting: surface mounted; each flange has (3) countersunk holes for #10 flat or oval head screws. Screws are not included.
• Curtain height: with a 72" (1829 mm) curtain (ASI 1200 or 1200-V) and 1200-SHU hooks, mount the rod centerline 74-1/2" (1892 mm) above the floor or 67" (1702 mm) above the tub rim for a 6" (152 mm) bottom overlap
• Rods longer than 72" (1829 mm) require ceiling support model 1204-C18
• Warranty: 1 year from date of invoice

Manufacturer spec sheet (flanges, model 1204-1)
